Maximize the full potential of your outdoor space with the Alcove pergola. Our only triangular design, the Alcove makes for the perfect upgrade to those smaller nooks, so you can enjoy every corner of your yard or patio. Crafted from premium weather-resistant vinyl, the Alcove pergola is maintenance-free and built to last.
Simple to assemble and install and comes with a 20-year limited warranty against manufacturing defects.
Tools Required: Cordless drill, level, tape measure, step ladder, shovel, cement (for in-ground installation)
Approx. Time Commitment: 2 people, 4-6 hours
Please note: Additional materials are required for installation and must be purchased separately (please review the assembly guide for more information).
If mounting pergola onto an existing concrete patio or deck (Note: not intended to be installed on top of patio stones or pavers):
· Steel Post Brackets (3) – 4x4 (10 cm x 10 cm)
· Pressure-Treated Wood Posts (3) – 4x4x8’ (10.2 cm x 10.2 cm x 243.8 cm)
· 2x6x8’ Pressure-Treated Boards (2)
· 2x6x10’ Pressure-Treated Boards (1)
· 2x6x12’ Pressure-Treated Boards (2)
· Cement Screws, Countersunk Head (9) – ¼” x 2 ¾” (0.64 cm x 7 cm)
· Concrete Drill Bit (1) – 3/16” (0.48 cm), min. 3” long
For a deck with an accessible underside:
· Steel Post Brackets (3) – 4x4 (10 cm x 10 cm)
· Pressure-Treated Wood Posts (3) – 4x4x8’ (10.2 cm x 10.2 cm x 243.8 cm)
· 2x6x8’ Pressure-Treated Boards (2)
· 2x6x10’ Pressure-Treated Boards (1)
· 2x6x12’ Pressure-Treated Boards (2)
· Bolts and Nuts, Countersunk Head (9) – ¼” (0.64 cm), length depends on blocking material
· Washers (9) – ¼” (0.64 cm)
· Wood Drill Bit (1) – ¼” (0.64 cm), min. 3” long
· Wood Blocks (4) – 2x10” (5.1 cm x 25 cm), to be secured between deck joists
If mounting pergola in the ground:
· Pressure-Treated Wood Posts (3) – 4x4x12’ (10.2 cm x 10.2 cm x 365.8 cm)
· 2x6x8’ Pressure-Treated Boards (2)
· 2x6x10’ Pressure-Treated Boards (1)
· 2x6x12’ Pressure-Treated Boards (2)
· Concrete Ready Mix (3)
a bit challenging to put together. Karen. Sleepy Hollow, IL. Thu Feb 13 2025
