Frost’s 340-B semi-recessed stainless steel waste disposals are compact and ideal for low volume areas. Typically, the disposals are used in schools/universities, restaurants, malls, office buildings, condominiums, fitness facilities, and recreation centres. The stainless steel construction and sleek appearance of this series make it a popular choice in low traffic areas.
Features:
• Made with 18 & 20 gauge Canadian stainless steel
• Secured with tumbler keyed lock, key provided
• All doors are hinged with full length stainless steel piano hinges
• Counterbalanced stainless steel door (20 gauge) provides maximum fire protection, mounted with full length piano hinge
• Removable leak proof roto moulded liner
Capacity:
• 22.5 litre capacity (5 Imp. gal., 6 gal. US)
Materials:
• Body: 18 gauge stainless steel
• Door: 20 gauge stainless steel type 304 no. 4 brushed finish
Product Dimensions:
• 34.8cm W x 96.8cm H 15.5cm D (13.7″ W x 38.1″ H x 6.1″ D)
Product Weight:
• 340-B – 13.2kg (29 lbs)
Installation Guidelines: Code 340-A: provide 31.5cm wide x 94.6cm high x 15.2cm deep (12⅜″ W x 37¾″ H x 6″ D) wall opening. Code 340-B: provide 31.5cm wide x 94.6cm high x 7.6cm deep (12⅜″ W x 37¾″ H x 3″ D) wall opening. Code 340-C: using the appropriate tools for installation, drill mounting holes as required and attached the unit into desired surface. Collar is secured between recessed body flange and wall. For unrestricted access, height of top of unit to floor must not exceed 144.7cm (57"). Please note that it is recommended that all installations be conducted by a qualified tradesperson. Please read and follow any additional installation guidelines provided with the products. Failure to do so may result in serious injury or death.
Maintenance: Normal preventative maintenance and cleaning will keep Frost products functioning properly and may extend normal product life. Products should be wiped down with a damp soft cloth periodically. Approved stainless steel cleaner may be used to clean scuffs or fingerprints on stainless surfaces. Do not use harsh detergents or chemical cleaners. For stainless steel please do not spray with any product containing bleach, acids, or chlorides, which can be found in many cleaning products such
